| 1 | Type: |
The T-type Joint Pipe (Push-on) |
| The K-type Joint Pipe | ||
| The Self-Restrained Joint Pipe | ||
| 2 | Standard: | ISO2531, EN545, EN598,etc |
| 3 | Size: | DN80~2600mm ( T-type Joint Pipe) |
| DN1200~2600mm ( K-type Joint Pipe) | ||
| DN80~1600mm (Self-Restrained Joint Pipe) | ||
| 4 | Thickness: | K9, K8, Class C |
| 5 | Length: | 6m, cut to 5.7m |
| 6 | Application: | Water supply project, drainage, sewage, irrigation, water pipeline. |
| 7 | Certificate: | ISO9001, BV, WRAS, BSI,CE |
8 |
Internal Coating: | a). Portland cement mortar lining |
| b). Sulphate Resistant cement mortar lining | ||
| c). High-Aluminum cement mortar lining | ||
| d). Fusion bonded epoxy coating | ||
| e). Liquid epoxy painting | ||
| f). Black bitumen painting | ||
9 |
External Coating: |
a). Zinc + bitumen painting |
| b). Fusion bonded epoxy coating | ||
| c). Zinc-aluminum alloy + liquid epoxy painting | ||
| 10 | Brand Name | SOLID |
| 11 | Packing: | Pipes which diameter under 300mm are bundled with steel belts, Others in bulk |
| Note: The coating can also be accordance with customers' requirements. | ||
